For the AAR M-101 standard axle of type G. The diameter of the axle journal is φ7.003(Inch) to φ7.004(Inch).

Back to the catalog

Axle of class G


O：Axle length
N: Bearing center distance
G: Journal Diameter
I: Wheel seat Diameter
W: Journal Length

Drawing No.
O (mm)
N (mm)
G (mm)
I (mm)
W (mm)
Weight
(kg)
Standard
RT-AW-05-021
2465.40
2171.83
157.26
222.25
296.80
555
AAR M-101
RT-AW-05-022
2266.95
2006.60
177.88
241.30
280.99
607.13
AAR M-101
RT-AW-05-023
2610
2350
177.80
240
281
869
AAR M-101
RT-AW-05-024
2457.20
2229.63
177.88
241.30
264.60
661.92
AAR M-101
RT-AW-05-025
2266.95
2006.60
177.88
241.30
280.99
607
AAR M-101
RT-AW-05-026
2266.95
2006.60
177.88
244.48
280.99
611.5
AAR M-101
RT-AW-05-114
2266.95
177.88
241.30
280.99
610.85
AAR M-101
RT-AW-05-254
2237.60
177
248
250
611.06
AAR M-101
RT-AW-05-255
2279.65
177.902
204.800
280.99
495.47
AAR M-101
RT-AW-05-433
1895.35
1625.6
157.277
203.2
340.56
392.47
AAR M-101
