For the AAR M-101 standard axle of type C. The diameter of the axle journal is φ4.6905(Inch) to φ4.6915(Inch).

Back to the catalog

Axle of class C


O：Axle length
N: Bearing center distance
G: Journal Diameter
I: Wheel seat Diameter
W: Journal Length

Drawing No.
O (mm)
N (mm)
G (mm)
I (mm)
W (mm)
Weight
(kg)
Standard
RT-AW-01-001
2435.40
2210
119.15
184
247.60
325.36
AAR M-101
RT-AW-01-002
1863.73
1638.30
119.16
177.62
247.65
271.81
AAR M-101
RT-AW-01-003
1787.50
1562
119.10
177.80
247.70
254.24
AAR M-101
RT-AW-01-004
1765.30
1539.80
119.16
117.80
247.65
241.64
AAR M-101
RT-AW-01-005
1815.40
1590
119.16
160
247.60
233.74
AAR M-101
RT-AW-01-048
2447.5
119
199
410.53
AAR M-101
RT-AW-01-049
2447.5
119
199
446.42
AAR M-101
RT-AW-01-064
1800.42
1575
119.16
175
247.64
262.80
AAR M-101
RT-AW-01-071
1865.42
119.16
188.50
279.15
JIS E4502
RT-AW-01-072
1865.42
119.16
188.50
313.44
JIS E4502
