For the AAR M-101 standard axle of type D. The diameter of the axle journal is φ5.1905(Inch) to φ5.1915(Inch).

Back to the catalog

Axle of class D


O：Axle length
N: Bearing center distance
G: Journal Diameter
I: Wheel seat Diameter
W: Journal Length

Drawing No.
O (mm)
N (mm)
G (mm)
I (mm)
W (mm)
Weight
(kg)
Standard
RT-AW-02-006
1755.8
1524
131.85
195.60
255.6
286.05
AAR M-101
RT-AW-02-007
2468
2236
1313.86
192
255.70
396.40
AAR M-101
RT-AW-02-008
1908
1676
131.86
196
255.50
304.5
AAR M-101
RT-AW-02-009
1755.8
1524
131.86
192.1
255.6
280.688
AAR M-101
RT-AW-02-010
1857.4
1625.6
131.86
191.7
255.6
300.5
AAR M-101
RT-AW-02-046
1819
1587.5
131.85
192.08
255.58
291.79
AAR M-101
RT-AW-02-055
1819.26
1587.5
131.85
192.08
291.93
AAR M-101
RT-AW-02-056
1749.8
131.84
191.71
255.6
279.43
AAR M-101
RT-AW-02-068
1762.2
136.7
200.4
308.53
AAR M-101
RT-AW-02-070
2384.5
136.70
222.30
446.1
AAR M-101
